PCB Mounting Surge Protector SLP20P-320

Location of Use: For PCB mounting

Surge Ratings: I_n = 10kA (8/20 μs)

IEC/EN Category: Class ll / Type 2

Protective Elements: High Energy MOV

Compliance: IEC/EN 61643-11

Main Specification

Model No.	SLP20P-320
	SPD according to IEC/EN 61643-11	Type 2 / Class II / Class C
	Nominal AC voltage U_n	230V
	Maximum continuous operating voltage (AC) U_c	320V
	Nominal discharge current (8/20 μs) I_n	10kA
	Maximum discharge current (8/20 μs) I_max	20kA
	Voltage protection level U_p	1.4kV
