LED Surge Protector SLP10-320S

Inline installation, for outdoor/commercial LED systems, with thermal protection and high discharge capacity due to MOV and gas discharge tube.

Applicable to class l or ll luminaire

Protection mode: L-N, L-PE, N-PE

Built in thermal separation function, higher safety

Series connection mode optional, with its own lead

Excellent surge impact resistance and low residual voltage

Miniature size and convenient for embedded installation

IP67 Water-proof and Dust-proof

Main Specification

Model No.	SLP10-320S
	SPD according to lEC/EN 61643-11	Class Il+lll / Type 2+3
	Nominal operating voltage (50/60 Hz) U_n	100-277V
	Maximum continuous operating voltage (50/60 Hz) U_c	320V
	Rated load current I_L	8A
	Nominal discharge current (8/20 μs) I_n	5kA
	Max. discharge current (8/20 μs) I_max	10kA
	Open-circuit voltage (1.2/50 μs & 8/20 μs) U_oc	10kV
	Voltage protection level (@ I_n) (L-N, L/N-PE) U_p	≤1.2kV
